HP DesignJet T520 36-in Standalone Printer (CH337A)
Product Number: CH337A
SKU: T520-42
In Stock
Call for Best Price414-321-1422
Overview from HP:
The most affordable standalone HP printer for small studios that print large-format technical documents in-house. The new Designjet 520 Printer series combines fine line and image quality to deliver high-impact results quickly and conveniently.
Features:
- Conveniently print large-format technical drawings
- Conveniently print CAD documents with print speeds up to 55 seconds for A1/D-sized documents.
- HP Instant Printing—quickly print your HP-GL/2 and PLT files with the simple click of a button.
- Easily share this large-format Designjet among multiple users with optional network capability.
- Delivers complete compatibility with the latest applications and operating systems.
- Reliable performance, high line, and image quality
- Produce quality images thanks to this printer's 2400 x 1200 optimized dpi resolution.
- High-quality output for technical CAD drawings—sharp detail, accurate lines, superior resolution.
- Process complex files with great ease thanks to 160 MB of memory.
- Based on the very reliable and best-selling HP Designjet 500 large-format printer series.
- Bring CAD printing in-house, at the right price
- Get high quality, high reliability at an affordable price.
- A choice of 28-ml and 69-ml HP ink cartridges enables cost-effective printing matched to your needs.
- Operation is easy and intuitive, so you can focus on key projects and not on your printer.
Specifications from HP:
| Printing Specifications | |
|---|---|
| Model size | 42 in |
| Print Speed | |
|---|---|
| Mechanical print time, US D color image, Best mode, glossy | 16 min/page |
| Mechanical print time, US D color image, Normal mode, glossy | 9.5 min/page |
| Mechanical print time, US D color image, Draft mode, coated | 2.5 min/page |
| Mechanical print time, US D color image, Normal mode, coated | 7 min/page |
| Mechanical print time, US D color line drawing, Draft mode, plain | 55 sec/page |
| Mechanical print time, US D b&w line drawing, Draft mode, plain | 55 sec/page |
| US D color line drawings/hr, Draft mode, plain | 38 D prints per hour |
| Memory | |
|---|---|
| Memory, standard | 160 MB |
| Hard disk | None |
| Printing | |
|---|---|
| Print technology | HP Thermal Inkjet |
| Resolution technology | HP Color Layering Technology |
| Print resolution, color | 2400 x 1200 dpi |
| Print resolution, black | 2400 x 1200 dpi |
| Non-Printable Area (imperial cut-sheet) | 0.7 x 0.7 x 0.2 x 0.2 in |
| Ink types | Dye-based (color), pigment-based (black) |
| Ink cartridges | 4 (1 each cyan, magenta, yellow, black) |
| Maximum roll length | Unlimited (depends on media thickness) |
| Line accuracy | +/- 0.2 % |
| Connectivity, standard | USB 2.0 compliant port; IEEE-1284-compliant parallel port; EIO Jetdirect accessory slot |
| Print languages, standard | HP-GL/2, HP-RTL, HP PCL 3 GUI |
| Paper Handling | |
|---|---|
| Document finishing | Single sheet feed, roll feed, automatic cutter (cuts all media except canvas) |
| Media types | Bond and coated, technical, film, photographic, proofing, self-adhesive, banner and sign, canvas |
| Media sizes, standard | 8.3 to 42-in wide sheets; 18 to 42-in rolls |
| Rolls External Diameter | 3.9 in |
| Compatible Operating Systems | |
|---|---|
| Compatible operating systems | Microsoft® Windows® 7, Windows Vista®, Windows® XP Professional, Windows® XP Home, Windows® Server 2008, Windows® Server 2003, Mac OS X v 10.4, Mac OS X v 10.5, Mac OS X v 10.6 |
| Dimensions and Weight | |
|---|---|
| Product dimensions (WxDxH) | 67 x 27 x 43 in |
| Weight | 99.6 lb |
| What's Included | |
|---|---|
| What's in the box | Printer; printer stand and media bin; spindle; printheads (4 x 1 color each); introductory ink cartridges; Quick Reference Guide; setup poster; start-up software; customer service guide; power cord |
| Warranty | One-year, next business day, on-site warranty |
